CNC Floor lathes, Max. swing diameters 1000 - 2500mm
This series of CNC face lathes covers those with swings as 1000mm, 1250mm, 1600mm, 2000mm and 2500mm. For larger swings than 2500mm, please talk with us to decide the customized specifications.
These CNC face lathes can perform rough or fine machining on workpieces by cylindrical turning, face turning, taper turning, turning on workpieces in other axisymmetrical shapes and turning vairous kinds of threads. It performs constant linear speed cutting to ensure a high machining precision. These CNC face lathes are widely used to cut wheel hubs, train wheel pairs, textile machine accessories and motor end covers, etc..
Specifications (Notes: Below shows our standard specifications. Customized specifications are available.)
| Specifications | NCFLX1000 | NCFLX1250 | NCFLX1600 | NCFLX2000 | NCFLX2500 |
| Chuck diameter, mm | 800 | 1000 | 1250 | 1600 | 2000 |
| Maximum swing diameter, mm | 1000 | 1250 | 1600 | 2000 | 2500 |
| Swing diameter over cross slide, mm | 600 | 800 | 1200 | 1500 | 1800 |
| Maximum workpiece length, mm | 700 | 700 | 1000 | 850 | 850 |
| Maximum workpice weight, KG | 1000 | 2000 | 2000 | 3000 | 3000 |
| Main motor power, KW | 7.5 | 15 | 15 | 22 | 22 |
| Spindle speeds, RPM | 10-300 | 10-300 | 10-110 | 4-80 | 4-60 |
| Spindle diameter, mm | 190 | 220 | 220 | 200 | 200 |
| Top slide feeding control | Stepless, variable 650frequency control | ||||
| Cross travel of top slide, mm | 500 | 650 | 800 | 800 | 800 |
| Longitudinal travel of top slide, mm | 700 | 700 | 1000 | 850 | 850 |
| CNC control system | Siemens, Fanuc, GSK control systems are available | ||||
