Features:
[1]
This knee-type universal horizontal milling machine is used
for milling the flat surfaces, the inclined surfaces, the curved surfaces,
the grooves, the slots, etc. with various cutters in large-batch production,
individual production, machining department, tools and repairing department;
[2] Accessories such as the universal milling head, the vertical
milling head, the slotting&milling head, the swivel table, the
universal dividing head can be mounted on this universal horizontal milling
machine to expand the range of applications;
[3] The worktable of this knee-type universal horizontal milling
machine can swivel 45° left and right. Using a dividing head on the machine,
all kinds of helical surfaces can be produced by swiveling the worktable
to a desired angle;
[4] Three-direction feed lead screws are trapezium lead screws;
[5] If mounted with a digital readout, workpiece can be measured during
milling to guarantee the machining quality of workpiece
and reduce operator labor intensity;
[6] This universal knee type milling machine can be used for boring
when mounted with a universal milling head.
STANDARD
ACCESSORIES:
HORIZONTAL MILLING
CUTTER ARBOR SUBASSEMBLY
MILLING CHUCK
MILLING CUTTER ARBOR
TAPER SLEEVE
DOUBLE ENDED WRENCH
SINGLE ENDED SPANNER
INNER HEXAGON SPANNER
|
Specifications |
Unit |
UHM320 |
|
|
Worktable size, L x W |
mm |
1320 x 320 |
|
|
T-slots on worktable |
Number |
Nos. |
3 |
|
Width |
mm |
18 |
|
|
Pitch |
mm |
80 |
|
|
Worktable travels |
Longitudinal (Manual/Power) |
mm |
800/700 |
|
Cross (Manual/Power) |
mm |
300/280 |
|
|
Vertical (Manual/Power) |
mm |
410/400 |
|
|
Worktable swivel angles, Maximum |
Degrees |
±45 |
|
|
Steps of worktable feeds |
|
18 |
|
|
Worktable power feed speed ranges |
Longitudinal |
mm/Minute |
15 - 750 |
|
|
Cross |
mm/Minute |
15 - 750 |
|
|
Vertical |
mm/Minute |
5.7 - 280 |
|
Worktable rapid traverse speeds |
Longitudinal |
mm/Minute |
2250 |
|
|
Cross |
mm/Minute |
2250 |
|
|
Vertical |
mm/Minute |
844 |
|
Distance between spindle centerline and ram |
mm |
155 |
|
|
Distance between worktable center and the vertical guideways |
mm |
235 - 535 |
|
|
Distance between spindle centerline and worktable top surface |
mm |
30 - 440 |
|
|
Diameters of arbors |
mm |
22, 27, 32 |
|
|
Spindle bore taper |
|
7:24, ISO 50 |
|
|
Spindle speeds |
RPM |
30 - 1500, 18 Steps |
|
|
Main motor power |
KW |
7.5 |
|
|
Feed motor power |
KW |
1.5 |
|
|
Machine overall sizes, L x W x H |
mm |
2327 x 1792 x 1720 |
|
|
Machine packing sizes, L x W x H |
mm |
2240 x 1900 x 2040 |
|
|
Machine net weight, Approx. |
KG |
3000 |
|
|
Voltage/Frequency of power supply |
|
380V/50Hz |
|
